Redis Persistence: RDB and AOF

#

Why Redis needs persistence?

#

Because Redis is an in-memory database So when the Redis service restarts, all data will disappear

However, you can use persistence settings Let Redis recover its state when it restarts !

Redis persistence settings

#

Redis provides two persistence settings They are RDB and AOF

• RDB: Redis Database
  RDB persistence performs point-in-time snapshots of your dataset at specified intervals.
• AOF: Append Only File
  AOF persistence logs every write operation received by the server. These operations can then be replayed again at server startup, reconstructing the original dataset.
• RDB+AOF: RDB and AOF
  You can enable both RDB and AOF persistence to provide a more robust data protection mechanism.

RDB: Redis Database

#

In short,
RDB needs to fork() a child process to save the point-in-time snapshot of your dataset to disk.

Advantages of RDB

#

RDB is a very compact single-file point-in-time representation of your Redis data.

• Space-efficient: RDB is more space-efficient than AOF
• Easier to Backup: RDB is easier to backup and restore

  since it is a single file, you can just copy it to any storage such as S3, Google Cloud Storage, etc.

• Faster restart with large datasets: RDB is faster to recover when you have a large dataset compared to AOF

Redis have utilized CoW to optimize the fork() process

Disadvantages of RDB

#

• Data loss: RDB is not good if you need to minimize data loss

  because it only saves the dataset at specified intervals

• Not suitable for large datasets: RDB is not suitable for large datasets

  Since it needs to fork() a child process to save the dataset to disk
  fork() can be slow if you have a large dataset
  may stop serving clients for some milliseconds or even seconds !

Detailed Implementation of RDB

#

We have mentioned that RDB needs to fork() a child process to save the dataset to disk.

Let’s take a look at the implementation of RDB in Redis source code.

1. From redis/src/rdb.c : define bgsaveCommand command entry point function.

   3907 3908 3909 3910 3911 3912 3913 3914 3915 3916 3917 3918 3919 3920 3921 3922 3923 3924 3925 3926 3927 3928 3929 3930 3931 3932 3933 3934 3935 3936 3937 3938 3939 3940 3941 3942

   /* BGSAVE [SCHEDULE] */ void bgsaveCommand(client *c) { int schedule = 0; /* The SCHEDULE option changes the behavior of BGSAVE when an AOF rewrite * is in progress. Instead of returning an error a BGSAVE gets scheduled. */ if (c->argc > 1) { if (c->argc == 2 && !strcasecmp(c->argv[1]->ptr,"schedule")) { schedule = 1; } else { addReplyErrorObject(c,shared.syntaxerr); return; } } rdbSaveInfo rsi, *rsiptr; rsiptr = rdbPopulateSaveInfo(&rsi); if (server.child_type == CHILD_TYPE_RDB) { addReplyError(c,"Background save already in progress"); } else if (hasActiveChildProcess() || server.in_exec) { if (schedule || server.in_exec) { server.rdb_bgsave_scheduled = 1; addReplyStatus(c,"Background saving scheduled"); } else { addReplyError(c, "Another child process is active (AOF?): can't BGSAVE right now. " "Use BGSAVE SCHEDULE in order to schedule a BGSAVE whenever " "possible."); } } else if (rdbSaveBackground(SLAVE_REQ_NONE,server.rdb_filename,rsiptr,RDBFLAGS_NONE) == C_OK) { addReplyStatus(c,"Background saving started"); } else { addReplyErrorObject(c,shared.err); } }

2. And bgsaveCommand actually calls rdbSaveBackground.
   rdbSaveBackground will check if there is already a child process running, if not, it will calls redisFork to fork a child process to save the dataset to disk.

   1612 1613 1614 1615 1616 1617 1618 1619 1620 1621 1622 1623 1624 1625 1626 1627 1628 1629 1630 1631 1632 1633 1634 1635 1636 1637 1638 1639 1640 1641 1642 1643 1644 1645 1646

   int rdbSaveBackground(int req, char *filename, rdbSaveInfo *rsi, int rdbflags) { pid_t childpid; if (hasActiveChildProcess()) return C_ERR; server.stat_rdb_saves++; server.dirty_before_bgsave = server.dirty; server.lastbgsave_try = time(NULL); if ((childpid = redisFork(CHILD_TYPE_RDB)) == 0) { int retval; /* Child */ redisSetProcTitle("redis-rdb-bgsave"); redisSetCpuAffinity(server.bgsave_cpulist); retval = rdbSave(req, filename,rsi,rdbflags); if (retval == C_OK) { sendChildCowInfo(CHILD_INFO_TYPE_RDB_COW_SIZE, "RDB"); } exitFromChild((retval == C_OK) ? 0 : 1); } else { /* Parent */ if (childpid == -1) { server.lastbgsave_status = C_ERR; serverLog(LL_WARNING,"Can't save in background: fork: %s", strerror(errno)); return C_ERR; } serverLog(LL_NOTICE,"Background saving started by pid %ld",(long) childpid); server.rdb_save_time_start = time(NULL); server.rdb_child_type = RDB_CHILD_TYPE_DISK; return C_OK; } return C_OK; /* unreached */ }

AOF: Append Only File

#

AOF utilizes the fsync() system call to save every write operation to disk.

Just like WAL (Write-Ahead Logging) in a relational database fsync is performed in background threads to avoid blocking the main Redis event loop.

AOF have 3 fsync policies:

• always: fsync() after every write operation
• everysec: fsync() every second (default)
• no: fsync() only when fsync() is called explicitly

  The faster and less safe method.
  Just put your data in the hands of the Operating System. Normally Linux will flush data every 30 seconds with this configuration, but it’s up to the kernel’s exact tuning.

AOF rewrite :

• Redis will rewrite the AOF file in the background to avoid the file becoming too large.
• serverCron will check if the AOF file is too large, if so, it will call rewriteAppendOnlyFileBackground to rewrite the AOF file in the background.

Similar to RDB, AOF rewrite also needs to fork() a child process to save the dataset to disk.
Which may encounter the same problems as RDB when you have a large dataset.

Advantages of AOF

#

• Less data loss: AOF is better if you need to minimize data loss

  since it saves every write operation to disk

Disadvantages of AOF

#

• Larger file size: AOF files are usually larger than the equivalent RDB files
• Slower than RDB (depends on fsync() policy):
  • Default everysec policy is still very efficient !
  • But if you set always policy, it will be slower than RDB since it needs to fsync() after every write operation
