2024 Dcard Backend Intern Assignment

·7 mins· ·
Blog En Backend Intern System-Design Dcard
Table of Contents

The gopher image is created by gophers.

My Dcard interview notes can be found here:

This post focuses on analyzing, designing, and implementing the backend internship assignment for Dcard 2024.
The final implementation can be found here:

GitHub Repository Thumbnail
jason810496/Dcard-Advertisement-API

Dcard Backend Intern Assignment 2024 . The assignment can be broadly defined as: Developing a read-heavy API (1000 requests per second) for querying time-series data within specific intervals under multiple conditions.

Go
4
0

Assignment Description
#

The full assignment details are available at:
https://github.com/jason810496/Dcard-Advertisement-API/blob/main/2024%20Backend%20Intern%20Assignment.pdf
Below is a simplified version:

Scenario
#

Using Golang, implement a simplified advertisement serving service that includes 2 RESTful APIs:

  1. Admin API: Create advertisements with conditions.
  2. Serving API: List all matching ads based on query conditions.

Detailed Explanation
#

Admin API

Only Create needs to be implemented (no need for List/Update/Delete).
Field structure:

  • Title: Advertisement title
  • StartAt: Ad start time (active time)
  • EndAt: Ad end time (active time)
  • Conditions: Ad display conditions
    • All conditions are optional
    • Each condition can have multiple selections
    • Condition structure:
      • Age: int:1~100
      • Gender: enum:M, F
      • Country: enum:TW, JP, ... (ISO 3166-1 compliant)
      • Platform: enum:android, ios, web

Serving API

Only List needs to be implemented (no need for Create/Update/Delete).

  • List active ads that match the conditions (StartAt < Now < EndAt).
  • Support query parameters for filtering ads.
  • Support pagination:
    • Use limit and offset to control results.
    • Sort by endAt in ascending order (ASC).

Requirements, Assumptions, and Constraints
#

Implementation Requirements
#

  • The serving API must handle over 10,000 RPS.
  • No need to implement authentication.
  • Validate parameters and handle errors appropriately.
  • Write proper tests.
  • Document the design choices and approach.

Assumptions and Constraints
#

  • No more than 3000 ads will be created daily.
  • Any third-party libraries are allowed.
  • Any external storage solutions are allowed.

API Example
#

Admin API: The following example represents an ad targeting users aged 20–30 in Taiwan or Japan, using Android or iOS, without gender restriction.

curl -X POST -H "Content-Type: application/json" \
  "http://<host>/api/v1/ad" \
  --data '{
     "title": "AD 55",
     "startAt": "2023-12-10T03:00:00.000Z",
     "endAt": "2023-12-31T16:00:00.000Z",
     "conditions": {
        {
           "ageStart": 20,
           "ageEnd": 30,
           "country": ["TW", "JP"],
           "platform": ["android", "ios"]
        }
     }
  }'

Serving API: Request example

curl -X GET -H "Content-Type: application/json" \
  "http://<host>/api/v1/ad?offset=10&limit=3&age=24&gender=F&country=TW&platform=ios"

Serving API: Response example

{
    "items": [
        {
            "title": "AD 1",
            "endAt": "2023-12-22T01:00:00.000Z"
        },
        {
            "title": "AD 31",
            "endAt": "2023-12-30T12:00:00.000Z"
        },
        {
            "title": "AD 10",
            "endAt": "2023-12-31T16:00:00.000Z"
        }
    ]
}

Analysis
#

The task can be summarized as:
Designing a read-heavy API capable of querying all records that match specific conditions over a certain time range.

The basic approach starts with caching, primarily using Redis for server-side caching.
The challenge is designing an efficient and low-cost cache solution.

Solution 1
#

When an ad is created, it is also stored in Redis.
A Gender:Platform:Country:AgeRange:uuid String key is created with a TTL based on the EndAt field.

`F:android:TW:20-30:uuid1`: "title1,end1",
`M:ios:JP:30-40:uuid2`: "title2,end2",

Creating an Ad:
When an ad is created in the DB, a goroutine is also triggered to create a corresponding Redis key.

Querying Ads:
Use SCAN to search and store results in a cache:Gender:Platform:Country:Age ZSet key.
The TTL is relatively short (e.g., 5–10 minutes).

This allows subsequent searches with the same conditions but different offset/limit values to query efficiently.
It’s like a secondary cache for searches, preventing repeated SCAN operations.

Deleting Ads:

  • For String keys: TTL is set during creation, so no further action is needed.
  • For ZSet keys: TTL is short (5–10 minutes), so no additional handling is required.

Pros
#

  • Each ad is stored as an independent key, making modifications easy.
  • Ads have corresponding TTLs, avoiding the need for a separate mechanism to expire ads in Redis.

Cons
#

  • Inefficient use of Redis:
    • Storing all DB data in Redis isn’t utilizing Redis purely as a cache.
  • Excessive key usage:
    • Assuming 10 countries:
      • 3000 active ads as Strings.
      • 2 * 3 * 100 * 10 (Gender * Platform * Age * Country).
      • 6000 ZSets for ad combinations.
      • At least 9000 keys.
  • Search efficiency is low:
    • Without a search cache, each SCAN has O(N) time complexity.
    • Additional processing is needed for age-based queries.

Solution 2
#

Partition by Age, using 101 Hashes:

  • Key: ad:Age (Age = all for all ages).
  • Mapping:
    • Key: Gender:Platform:Country.
    • Value: Serialized ad list.
ad:0: {
        `F:android:TW`: [],
        `M:ios:JP`: [],
        ...
},
ad:1: {
        `Gender:Platform:Country`: [],
        ...
},
...
ad:99: {
        `Gender:Platform:Country`: [],
        ...
},
ad:all: {
        `Gender:Platform:Country`: [],
        ...
}

Creating an Ad:
The ad is stored in the corresponding partitions for ageStart to ageEnd.
This requires a Lua Script to ensure ACID properties.

Querying Ads:
Use HSCAN with the MATCH option to filter ads in the corresponding partition.
HSCAN returns a cursor for pagination.

Deleting Ads:
A cron job periodically checks all partitions to clean up expired ads.
Depending on consistency requirements, you might use Lua Script for ACID guarantees.
Otherwise, HSCAN + HDEL is a sufficient alternative.

System Architecture
#

Initial Architecture
#

Originally, for Redis caching, I planned to use the Redis Sentinel architecture

  • To achieve High Availability and Read Scalability.
flowchart TD
    Ingress[Ingress]

    subgraph APCluster["`**Stateless AP**`"]
        subgraph AP1LocalCache[Local Cache]
        AP1[AP 1]
        end
        subgraph AP2LocalCache[Local Cache]
        AP2[AP 2]
        end
        subgraph AP3LocalCache[Local Cache]
        AP3[scale by k8s ...]
        end
    end
    %% Ingress --> AP1 & AP2 & AP3

    subgraph HAProxyCluster[HAProxy Deployment]
    HAProxy1[Proxy instance]
    HAProxy2[Standby]
    end

    subgraph RedisCluster["`Redis **sentinel**`"]
    RedisReplica1[(Replica 1)]
    RedisMaster[(Primary)]
    RedisReplica2[(Replica 2)]
    end

    Ingress --> APCluster -- Public API
    ( Query active AD )--> HAProxyCluster
    HAProxyCluster -- load balance Read request --> RedisCluster
    %% HAProxyCluster --> RedisReplica1 & RedisReplica2

    subgraph PgCluster["`Postgres **Primary Replica**`"]
    PG[(Postgres\nPrimary)]
    PgReplica[(Postgres\nReplica)]
    PG -- WAL --> PgReplica
    end

    RedisMaster & RedisReplica1 & RedisReplica2 ---> PG & PgReplica
    APCluster == Admin API
    ( Create AD ) ==> PG


    %% subgraph CornWorkers[Cornjob Workers]
    %% ActiveWorker[Cornjob: Pre-heat AD]
    %% DeactiveWorkder[Cornjob: Deactive AD]
    Corn[CornJob]
    %% end

    %% PG <--> ActiveWorker --> RedisMaster
    %% PG <--> DeactiveWorkder --> RedisMaster

    RedisMaster <-- Pre-heat or aeactive AD
    ( use Lua script for atomic operation ) --> Corn <-- Query oncomming AD--> PG

Final Architecture
#

flowchart TD
    Ingress[Ingress]


    Ingress --> APCluster

    subgraph APCluster["`**Stateless AP**`"]

        subgraph AP2LocalCache[Local Cache]
        AP2[AP 2]
        BG2[BG goroutine]
        AP2 -.- BG2
        end

        subgraph AP1LocalCache[Local Cache]
        AP1[AP 1]
        BG1["`Internal goroutine
        refresh local Cache`"]
        AP1 -.- BG1
        end




        subgraph AP3LocalCache[Local Cache]
        AP3[scale by k8s ...]
        BG3[BG goroutine]
        AP3 -.- BG3
        end
    end


    Redis[("Redis standalone")]


    AP1LocalCache -. "`Public API
    (if cached)`" .-> Redis

    AP1LocalCache -. "`Public API
    (if cached)`" .-> Redis


    subgraph PgCluster["`Postgres **Primary Replica**`"]
    PG[(Postgres\nPrimary)]
    PgReplica[(Postgres\nReplica)]
    PG -- WAL --> PgReplica
    end

    AP2LocalCache -. "`Public API
    (if not cache)`" .-> PG & PgReplica

    AP3LocalCache -. "`Public API
    (if not cache)`" .-> PG & PgReplica

    AP3LocalCache == Admin API
    ( Create AD ) ==> PG


    Corn[CornJob]

    Redis <-. "`Pre-heat or daeactive AD
    ( use **Lua** script for atomic operation )`" .-> Corn <-.-> PG

Data Bottleneck: Postgres
#

Even with Redis serving as the server-side cache,
the QPS still did not meet the initial target,
and there was still a large amount of traffic hitting Postgres.

From the CPU and Memory usage:
Postgres CPU utilization reached 90%.

The solution at that time was to add an additional layer of Local Cache at the API level,
with a background goroutine periodically updating the Local Cache.

After adding this Local Cache layer,
the system managed to reach the goal of 10,000 RPS locally.

Areas for Further Optimization
#

As I write this retrospective in September 2024,
I’ve noticed some details that were overlooked in the original implementation:

  1. Database Indexing
  2. System Stability
  3. Sharding

Database Indexing
#

Back then, I used the Gorm ORM to interact with Postgres.
Gorm only creates an index on the Primary Key,
but does not index other fields.

It would be useful to benchmark different combinations of indexes
and determine which fields benefit from adding specific types of indexes for better performance.

System Stability
#

At the time, when I realized that Redis caching still resulted in substantial traffic to Postgres,
I didn’t consider system stability.
Instead, I hastily added a layer of Local Cache to hit the QPS target.

I should have used singleFlight
to prevent high traffic from overwhelming Postgres,
(at least filtering out duplicate queries).
This would have kept Postgres QPS within a reasonable range
and ensured overall system stability.

Sharding
#

During the interview follow-up on scalability,
questions like: “What if there are 30 countries and 5 platforms?” arose.
How do you maintain the same QPS target?

It’s easy to mention sharding,
but in practice, implementing a stable, scalable system using sharding isn’t that simple.
If I had the opportunity, I would like to experiment with implementing it.
